Full Description

The purpose of this Practice is to provide the typical details for construction of grounding systems in chemical and refining facilities. The bonding and grounding design and installation shall be in accordance with the National Electrical Code.

These installation details include power system and equipment grounding, static grounding protection for equipment in classified locations, grounding electrode connections, and step and touch potential grounding.

Not included in the scope of this Practice are computer and control system grounding and cathodic protection.

Product Details

Published: 01/01/2010 Number of Pages: 49 File Size: 1 file , 1.8 MB
