Full Description

This document contains a wide variety of photographic illustrations of various anomalies and characteristics of printed boards for identification of anomalies that are sometimes seen during inspection and evaluation processes. The handbook has been divided into fourteen distinct sections covering topics such as solder resist, plated-through holes, conductor characteristics and surface plating to aid the user in determining specific accept/nonconforming criteria for various anomalies.

Product Details

Published: 02/01/1999 Number of Pages: 52 File Size: 1 file , 5.4 MB
