IPC 2223A
IPC 2223A Sectional Design Standard for Flexible Printed Boards
standard by Association Connecting Electronics Industries, 06/01/2004
Reduced price!
M00001450
New product
Full Description
Used in conjunction with IPC-2221A, IPC-2223 establishes the requirements for the design of single-sided, double-sided, multilayer, or rigid-flex flexible circuits. Revision A includes updated design rules for panel sizes, hole spacing, bend radii, shielding, palletization, nonfunctional lands, coverlayer access/spacing and conductor edge spacing.
