Full Description

Provides specific test methods to evaluate the performance and reliability of surface mount solder attachments of electronic assemblies. Establishes levels of performance and reliability of the solder attachments of surface mount devices to rigid, flexible and rigid-flex circuit structures. When used with IPC-SM-785, it provides an understanding of the physics of SMT solder joint failure and an approximate means of relating performance tests results to the reliability of solder attachments in their use environments. Revision A includes Appendix B which provides recommended changes to the thermal cycling profiles given in the document when utilizing Pb-free solder joints.

Product Details

Published: 01/01/2006 ISBN(s): 9781611933628 Number of Pages: 50 File Size: 1 file , 700 KB Product Code(s): 5-HB-0-D-0-CN-0
