Full Description

Scope

This guide discusses the reasons why a termination is necessary on a shielded power cable. The guide includes a short tutorial on termination theory, a general discussion of design and materials and a selection flow chart and an application spacing guide.

Purpose

The purpose of this project is to guide the reader in selecting and applying terminations for shielded-power cables rated 5 kV - 46 kV.

Abstract

Revision Standard - Active - Draft.A step-by-step process for selecting an appropriate termination that is commensurate with a particular shielded power cable design is provided in this guide. Over the years, shielded power cables have been developed that employ many different insulating materials and many different shielding systems, such that, there are numerous issues to consider when selecting a termination for a particular cable design. Over the same period of time, many different termination methods and designs have been developed that serve the same purpose, but employ different application methodologies.This guide does not attempt to cover every cable and termination design, and is generally restricted to single conductor underground residential distribution (URD) and shielded power cable that have a voltage rating from 5 kV to 46 kV, which includes some industrial cables. By nature, the terminations referred to in this guide are considered to be a??live front,a?? in that the terminations comprise a transition from a shielded power cable system to an energized component or bus that is either bare or simply covered.

Product Details

ISBN(s): 9781504468794 Number of Pages: 61 File Size: 1 file , 5.2 MB Product Code(s): STDAPE24300
