Scope

This document provides general guidelines toward the preparation of a functional specification of transmission static var compensators (SVCs) using conventional thyristor technology. Many clauses will be useful for compensator systems using gate turn-off (GTO) thyristor technology [static compensator (STATCOM)] or other semiconductor devices, or SVCs associated with high-voltage dc (HVDC) converter stations, or industrial and distribution applications. General terms and conditions forming the commercial part of a specification for a particular project are outside the scope of this document.

Purpose

Starting at Clause 4, this document presents technical clauses that may be used as the basis of a functional SVC specification. The wording deliberately uses shouldA? rather than shallA? because this document is a guide, not a specification. The user of this guide might wish to make this adjustment when converting clauses into a specification. Annex B of this document contains supplemental information intended to further develop specific clauses. Further information is referenced by the same subdivision numbering used in the main text.

Abstract

Revision Standard - Superseded.This guide documents an approach to preparing a specification for a transmission static var compensator. The document is intended to serve as a base specification with an informative annex provided to allow users to modify or develop specific clauses to meet a particular application.

Product Details

Published: 04/21/2000 ISBN(s): 073811944X, 9780738119458 Number of Pages: 55 File Size: 1 file , 470 KB Product Code(s): STDSU94815
