Full Description

Scope

This application guide applies to the ac indoor and outdoor high-voltage circuit breakers rated in accordance with the methods given in IEEE Std. C37.04-1999, listed in IEEE Std. C37.06-1997, and tested in accordance with IEEE Std. C37.09-1999. Circuit breakers rated and manufactured to meet other standards should be applied in accordance with application procedures adapted to their specific ratings or applications.

Abstract

Revision Standard - Superseded.This guide covers the application of indoor and outdoor high-voltage circuit breakers rated above 1000 V for use in commercial, industrial, and utility installations. It deals with usage under varied service conditions, temperature conditions affecting continuous current compensation, reduced dielectrics, reclosng derating as applicable, calculation of system short-circuit current, compensation at different X/R ratios, detailed calculations with application curves, out-of-phase switching, and general application.

Product Details

Published: 05/31/2000 ISBN(s): 9781504419413, 9780738118284 Number of Pages: 80 File Size: 1 file , 1.1 MB Product Code(s): STDSU94796, STDPL94796
