Full Description

Scope

The scope of this guide is to provide manufacturers of gaskets and designers of electronic systems appropriate methods for the characterization of gaskets. This document will guide the user in the selection of the appropriate test method in order to determine the level of shielding provided in the intended application.

Purpose

The purpose of this guide is to provide guidance on the strengths and weaknesses of each of the recommended methods, and provide in-depth documentation for each method. Therefore, it identifies limitations and sources of errors of the commonly accepted techniques for measuring gaskets, and provides a basis for comparing the various accepted techniques. It encompasses measurements of the as-installed behavior of gaskets as well as manufacturing-related quality control measurements. Special attention is also given to test methods for small samples of gaskets (also above 1 GHz), correlation between different methods, and to identify possible measuring methods for near-field characterization of gaskets [as used on printed circuit board (PCB) board applications].

Abstract

Revision Standard - Superseded.The scope of the proposed project is to provide manufacturers of gaskets and designers of electronic systems appropriate methods for the characterization of gaskets. It will guide the user in the selection of the appropriate test method in order to determine the level of shielding provided in the intended application.

Product Details

Published: 02/09/2009 ISBN(s): 9780738158334, 9780738158327 Number of Pages: 44 File Size: 1 file , 2.3 MB Product Code(s): STDSU95849
