Full Description

IEC 60534-3-1:2019 specifies face-to-face (FTF) and centre-to-face (CTF) dimensions for given nominal sizes and pressure ratings of flanged, two-way, globe-type, straight pattern and angle pattern control valvesThis second edition cancels and replaces the first edition published in 2000. This edition constitutes a technical revision.
This edition includes the following significant technical changes with respect to the previous edition:
a)This standard has been extended to cover face-to-face dimensions and centre-to-face dimensions for control valves PN 160 and PN 250 (Class 900 and 1500)
b)Definitions of end-to-end dimensions and centre-to-end dimensions have been added for valves with flange facings where the gasket contact surfaces are not located at the extreme ends of the valve
c)Table 5 of adjustment value "X" for end-to-end dimensions of straight pattern valves with ring joint ends has been added
d)ANSI/ISA references have been added in Tables 1 to 4
e)ANSI/ISA references have been added in the bibliography

Product Details

Edition: 2.0 Published: 02/06/2019 Number of Pages: 26 File Size: 1 file , 2 MB
