IEC 63093-4:2019 specifies the dimensions that are of importance for mechanical interchangeability for a preferred range of RM-cores and low-profile RM-cores made of ferrite, and the locations of their terminal pins on a 2,54 mm printed wiring grid in relation to the base outlines of the cores. It also gives guidance on allowable limits of surface irregularities applicable to RM-cores in accordance with the relevant generic specification.

The selection of core sizes for this document is based on the philosophy of including those sizes which are industrial standards, either by inclusion in a national standard, or by broad-based use in industry.

This document is a specification useful in the negotiations between ferrite core manufacturers and customers about surface irregularities.

This first edition cancels and replaces the first edition of IEC 62317-4 published in 2005 and the second edition of IEC 60424-2 published in 2015. This edition constitutes a technical revision.

Product Details

Edition: 1.0 Published: 03/08/2019 Number of Pages: 68 File Size: 1 file , 4.9 MB
