Full Description

Provides information on land pattern geometries used for the surface attachment of electronic components with area array terminations in the form of solder balls, solder columns or protective coated lands. The intent of the information presented herein is to provide the appropriate size, shape and tolerances of surface mount land patterns to ensure sufficient area for the appropriate solder joint, and also allow for inspection, testing and reworking of those solder joints.

Product Details

Edition: 1.0 Published: 10/30/2007 Number of Pages: 30 File Size: 1 file , 1 MB
