Full Description

IEC 60906-2:2011 applies to the IEC system of plugs and socket-outlets rated 15 A 125 V a.c. and 20 A 125 V a.c. for household and similar purposes, for the connection of equipment to distribution systems having nominal voltages between 100 V and 130 V a.c. in so far as dimensional requirements are concerned. This third edition of IEC 60906-2 cancels and replaces the second edition published in 1997, and constitutes a technical revision. The main changes from the previous edition are as follows:
- revision to tolerances on the slot dimensions;
- incorporate a shorter maximum length of blade;
- new dimensions to define the recess of electrical contacts;
- new gage for inspection to verify dimensional compliance to protection from electrical shock during partial insertion and withdrawal of plug blades.

Product Details

Edition: 3.0 Published: 05/12/2011 Number of Pages: 28 File Size: 1 file , 3.3 MB
