Full Description

1.1This general requirements specification covers a group of common requirements that, unless otherwise specified in the applicable product specification, apply to rolled structural steel bars, plates, shapes, and sheet piling covered by each of the following product specifications issued by ASTM:

1.2Annex A1 lists permitted variations in dimensions and mass (Note 1) in SI units. The values listed are not exact conversions of the values in Tables1 to 31 inclusive but are, instead, rounded or rationalized values. Conformance to Annex A1 is mandatory when the M specification designation is used.

Note 1:The term weight is used when inch-pound units are the standard; however, under SI, the preferred term is mass.

1.3Annex A2 lists the dimensions of some shape profiles.

1.4Appendix X1 provides information on coil as a source of structural products.

1.5Appendix X2 provides information on the variability of tensile properties in plates and structural shapes.

1.6Appendix X3 provides information on weldability.

1.7Appendix X4 provides information on cold bending of plates, including suggested minimum inside radii for cold bending.

1.8This general requirements specification also covers a group of supplementary requirements that are applicable to several of the above product specifications as indicated therein. Such requirements are provided for use where additional testing or additional restrictions are required by the purchaser, and apply only where specified individually in the purchase order.

1.9In case of any conflict in requirements, the requirements of the applicable product specification prevail over those of this general requirements specification.

1.10Additional requirements that are specified in the purchase order and accepted by the supplier are permitted, provided that such requirements do not negate any of the requirements of this general requirements specification or the applicable product specification.

1.11For purposes of determining conformance with this general requirements specification and the applicable product specification, values are to be rounded to the nearest unit in the right-hand place of figures used in expressing the limiting values in accordance with the rounding method of Practice E29.

1.12The text of this general requirements specification contains notes or footnotes, or both, that provide explanatory material. Such notes and footnotes, excluding those in tables and figures, do not contain any mandatory requirements.

1.13The values stated in either inch-pound units or SI units are to be regarded separately as standard. Within the text, the SI units are shown in brackets. The values stated in each system are not exact equivalents; therefore, each system is to be used independently of the other, without combining values in any way.

1.14This general requirements specification and the applicable product specification are expressed in both inch-pound units and SI units; however, unless the order specifies the applicable M specification designation (SI units), the structural product is furnished to inch-pound units.

1.15This standard does not purport to address all of the safety concerns, if any, associated with its use. It is the responsibility of the user of this standard to establish appropriate safety and health practices and determine the applicability of regulatory limitations prior to use.
