Full Description

1.1This specification covers deformed and plain stainless steel bars for concrete reinforcement in cut lengths and coils used in applications requiring resistance to corrosion or controlled magnetic permeability. The standard sizes and dimensions of deformed bars and their numerical designation shall be those listed in Table 1.

1.1.1A supplementary requirement (S1) is provided for use where a controlled magnetic permeability product is required by the purchaser. Supplementary requirement (S1) applies only when specified in the purchase order.

1.2The chemical composition of the stainless steel alloy shall be selected for suitability to the application involved by agreement between the manufacturer and the purchaser. This is an important consideration in achieving the desired corrosion resistance or controlled magnetic permeability, or both, because these properties are not provided by all stainless steels.

1.3Corrosion Resistance requirements are contained in Section 11 and Annex A1 and the test procedures options are Annex A2 (Rapid Macrocell Test) or Annex A3 (Cracked Beam Test).

1.4The requirements for introduction of new alloys into a mandatory chemical composition requirements table in this specification are given in Annex A5.

1.5Requirements for the relative deformation area of three-sided deformed bars are contained in Annex A4.

1.6Bars are of three minimum yield strength levels, namely, 60 000 psi [420 MPa], 75 000 psi [520 MPa], and 80 000 psi [550 MPa], designated as Grade 60 [420], Grade 75 [520], or Grade 80 [550], respectively.

1.7Plain bars in sizes up to and including 2 in. [50.8 mm] in diameter in coils or cut lengths are furnished in accordance with this specification in Grade 60 [420], Grade 75 [520], and Grade 80 [550], respectively. Mechanical testing, when required, shall be to the nearest nominal deformed bar size. Requirements providing for deformations and marking shall not be applicable to plain bars.

1.8When stainless steel is to be welded, use a procedure suitable for the chemical composition and intended use or service.

Note 1:Welding of stainless steel reinforcement would occur after shipment from the manufacturer. Structural welding should be performed in accordance with the latest edition of AWS D1.6/D1.6M, any other internationally accepted stainless steel welding code, or a procedure suggested by the material manufacturer. AWS D1.6/D1.6M describes the proper selection of the filler metals, temperature control, as well as, performance, procedure qualification and inspection requirements.

1.9This specification is applicable for orders in either inch-pound units (as Specification A955) or in SI units (as Specification A955M).

1.10The text of this specification references notes and footnotes which provide explanatory material. These notes and footnotes (excluding those in tables and figures) shall not be considered as requirements of the specification.

1.11The values stated in either inch-pound or SI units are to be regarded separately as standard. Within the text, the SI units are shown in brackets. The values stated in each system may not be exact equivalents; therefore, each system shall be used independently of the other. Combining values from the two systems may result in nonconformance with the specification.

1.12This specification does not purport to address all of the safety concerns, if any, associated with its use. It is the responsibility of the user of this specification to establish appropriate safety, health, and environmental practices and determine the applicability of regulatory limitations prior to use.

1.13This international standard was developed in accordance with internationally recognized principles on standardization established in the Decision on Principles for the Development of International Standards, Guides and Recommendations issued by the World Trade Organization Technical Barriers to Trade (TBT) Committee.
