Full Description

This document specifies requirements and gives recommendations for the design, material selection, manufacture, design verification, testing, installation and operation of subsea control systems, chemical injection, gas lift, utility and service umbilicals and associated ancillary equipment for the petroleum and natural gas industries. This also applies to umbilicals containing electrical conductors, optical fibres, thermoplastic hoses and metallic tubes, either alone or in combination; and applies to umbilicals that are for static or dynamic service, and with routings of surface-surface, surface-subsea and subsea-subsea.

Product Details

Edition: 4th Published: 10/01/2010 ANSI: ANSI Approved Number of Pages: 167 File Size: 1 file , 1.6 MB Redline File Size: 2 files , 3.9 MB Same As: ISO 13628-5:2009 Product Code(s): GX17E04, GX17E04, GX17E04 Note: This product is unavailable in Cuba, Iran, North Korea, Syria
